Victron Energy Phoenix Battery Charger
Victron Energy Phoenix Battery Charger
Victron Energy Phoenix Battery Charger
Victron Energy Phoenix Battery Charger
Victron Energy Phoenix Battery Charger
Victron Energy Phoenix Battery Charger
Victron Energy Phoenix Battery Charger
Victron Energy Phoenix Battery Charger

Victron Energy Phoenix Battery Charger

$1,300.00
Tax included. Shipping calculated at checkout.
Model

 The Victron Energy Phoenix Charger features a microprocessor controlled ‘adaptive’ battery management system that can be preset to suit different types of batteries. The ‘adaptive’ feature will automatically optimise the process relative to the way the battery is being used.



The Right Amount of Charge: Variable Absorption Time

When only shallow discharges occur (a yacht connected to shore power for example) the absorption time is kept short in order to prevent overcharging of the battery. After a deep discharge the absorption time is automatically increased to make sure that the battery is completely recharged.

Preventing Damage Due to Excessive Gassing: BatterySafe Mode

If, in order to quickly charge a battery, a high charge current in combination with a high absorption voltage has been chosen, the Phoenix Charger will prevent damage due to excessive gassing by automatically limiting the rate of voltage increase once the gassing voltage has been reached.

Less maintenance and aging when the battery is not in use: Storage mode

The storage mode kicks in whenever the battery has not been subjected to discharge during 24 hours. In the storage mode float voltage is reduced to 2.2 V/cell (13.2 V for a 12 V battery) to minimise gassing and corrosion of the positive plates. Once a week the voltage is raised back to the absorption level to ‘equalize’ the battery. This feature prevents stratification of the electrolyte and sulphation, a major cause of early battery failure.

To Increase Battery Life: Temperature Compensation

Every Phoenix Charger comes with a battery temperature sensor. When connected, charge voltage will automatically decrease with increasing battery temperature. This feature is especially recommended for sealed batteries and/or when important fluctuations of battery temperature are expected.

Battery Voltage Sense

In order to compensate for voltage loss due to cable resistance, Phoenix Chargers are provided with a voltage sense facility so that the battery always receives the correct charge voltage.



Specifications:

 Model 12/50 24/25
Input Voltage Range 90-265V AC 90-265V AC
Input Voltage Range 90-400V DC 90-400V DC
Charge Voltage - Absorption 14.4V DC 28.8V DC
Charge Voltage - Float 13.8V DC 27.6V DC
Storage Mode 13.2V DC 26.4V DC
Charge Current - House Battery 50A 25A
Charge Current - Start Battery 4A 4A
Battery Capacity 200-800Ah 100-400Ah
Weight 3.8Kg

3.8Kg

Dimensions H350 x W200 x D108mm

H350 x W200 x D108mm



5 Year Warranty
